Data sheet
- Brand
- RHP
- Reference
- H3044
- Inside diameter (MM)
- 200
- Inside diameter (INCH)
- 7.874"
- Outside diameter (MM)
- 260
- Outside diameter (INCH)
- 10.236"
- Width (MM)
- 126
- Width (INCH)
- 4.961"
- Internal clearance
- Normal
- Cage type
- Steel cage or standard
- Bore type
- *
- Sealing type
- *
- Customs code
- 84829900
Adapter Sleeves And Accessories H3044
RHP
Adapter Sleeves H3044 are essential accessories for securing mechanical components in a wide range of industrial applications. These H... Adapter Sleeves are designed for reliability. Frequently used to mount tapered-bore bearings on cylindrical shaft seats.
Professionals?
Log in to benefit from your prices
Description
INDICATIVE DESCRIPTION
The adapter sleeve and accessories H3044, the solution to your needs?
What to say about the adapter sleeve H3044 with KM lock nut and MB lock washer, metric dimensions
Adapter sleeves H3044 are the most commonly used components for locating bearings with a tapered bore onto a cylindrical seat as they can be used on plain shafts or stepped shafts.
They are usually slit and are supplied complete with a KM lock nut and a MB lock washer.
Here are the important points to note about adapter sleeves H3044
- Easy to install
- Complete with lock nut
- Complete with locking device
Reference bearings, electric motors and geared motors for your needs
Texime offers you a vast choice of bearings: ball bearings, thrust bearings, radial spherical plain bearings, angular contact ball bearings, roller bearings, tapered roller bearings, cylindrical roller bearings, thrust bearings, spherical plain bearings, etc., electric motors: 220v electric motors, three-phase motors and geared motors: 220v geared motors, three-phase geared motors...
Adapter Sleeves H3044 are essential accessories for securing mechanical components in a wide range of industrial applications. These H... Adapter Sleeves are designed for reliability. Frequently used to mount tapered-bore bearings on cylindrical shaft seats.
