Data sheet
- Brand
- NTN
- Reference
- 5308/C3
- Inside diameter (MM)
- 40
- Inside diameter (INCH)
- 1.575"
- Outside diameter (MM)
- 90
- Outside diameter (INCH)
- 3.543"
- Width (MM)
- 36.5
- Width (INCH)
- 1.437"
- Internal clearance
- C3
- Cage type
- Steel cage or standard
- Bore type
- Cylindrical
- Sealing type
- *
- Customs code
- 84821090
Double Row Angular Contact Ball Bearing 5308/C3
NTN
The 5308/C3 double row angular contact ball bearing is a high-quality double row angular contact ball bearing for your needs. It is composed of various technical characteristics, which are listed below. Ordering and consulting Texime means working with a technical and sales team with over 20 years' professional experience.
Professionals?
Log in to benefit from your prices
Description
INDICATIVE DESCRIPTION
5308/C3 Double row angular contact ball bearings
Double row angular contact ball bearings such as part no. 5308/C3 correspond, in their design and operation, to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space.
They can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions.
Summary of characteristics of double row angular contact ball bearings
- High-speed capability
- Accommodate relatively high radial loads, high axial loads in both directions and tilting moments
- Suitable where a stiff bearing arrangement is required
- Require less axial space than equivalent pair of single row angular contact ball bearings
Order your 5308/C3 double row angular contact ball bearing on Texime
Do you need the 5308/C3 double-row angular contact ball bearing? Order from Texime. We're a sales and technical team, and your satisfaction and response to your needs are important to us. Contact Texime!
The 5308/C3 double row angular contact ball bearing is a high-quality double row angular contact ball bearing for your needs. It is composed of various technical characteristics, which are listed below. Ordering and consulting Texime means working with a technical and sales team with over 20 years' professional experience.
