Data sheet
- Brand
- FAG
- Reference
- 2205-2RS-TVH
- Inside diameter (MM)
- 25
- Inside diameter (INCH)
- 0.984"
- Outside diameter (MM)
- 52
- Outside diameter (INCH)
- 2.047"
- Width (MM)
- 18
- Width (INCH)
- 0.709"
- Internal clearance
- Normal
- Cage type
- Steel cage or standard
- Bore type
- Cylindrical
- Sealing type
- Rubber seals on both sides
- Customs code
- 84821090
Self Aligning Ball Bearings 2205-2RS-TVH
FAG
Find all the characteristics of the 2205-2RS-TVH self-aligning ball bearing below and order on our Texime website or contact us!
Professionals?
Log in to benefit from your prices
Description
INDICATIVE DESCRIPTION
What are self-aligning ball bearings like the 2205-2RS-TVH?
Self-aligning ball bearing with seals or flanges on both sides have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring.
They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection.
What to remember about self-aligning ball bearings like 2205-2RS-TVH?
- Accommodate static and dynamic misalignment
- Excellent high-speed performance
- Excellent light load performance
- Low friction
2205-2RS-TVH, a sealed bearing
Integral seals can significantly improve the service life of the bearing, as they retain the lubricant and prevent the ingress of impurities.
Find all the characteristics of the 2205-2RS-TVH self-aligning ball bearing below and order on our Texime website or contact us!
